Using advanced lithium battery manufacturing process, strong output energy.
Provide AC output and DC output two different output modes to match the demand of different electronic products.
This product can be used in both on-line UPS power supply and outdoor emergency standby power supply.
The product is equipped with multiple lithium batteries, with a total capacity of 11.1V 45000mah (166.5Wh).After the electricity, in the case of not shutting down, it can be used for 3~6 hours for ordinary household desktop computers.
3 charging methods.Meet different scenarios.It has three charging methods: AC / Solar / Car Charger, which can meet the requirements of various devices. It has a multi-interface design and multiple devices can be charged at the same time.
166.5Wh large capacity.Excellent compatibility.Equipped with 45000 lithium ion battery, powerful battery, compatibility is more durable than ordinary battery.
Specification
Model number: OKD 180
Power: 180W
Size : 200*115*90 mm
LED Light: 3 W
Charging input:CC/CV15V/2A
AC Output :100V~240V 50~60Hz
QC3.0 output:5V=3A 9V=2A
PD Output:65W
USB Output:5V/3A
DC Output:12V/10A(M ax.)
Solar charging input:12.6V-18V=5A(Max)
Transient Response Time: <5MS
Operation Temperature:-20°C~45°C
Lithium Battery Energy : 166.5 Wh
Lithium Battery Capacity : 15Ah/11.1V [ 45000 mAh ]
MPPT (Maximum Power Point Tracking)Solar Charge Controller offer an efficient, safe, multi-stage recharging process that prolongs battery life and assures peak performance from a solar array. Each Charge Controller allows customized battery recharging
Features
Name : MPPT Solar Charge Controller
Model : PC1800 [ PC18-6025F ]
Current : 60A
Battery Voltage : 12VDC/24VDC/36VDC/48VDC
Min Solar Voltage : 15VDC For 12VDC Battery System
30VDC For 24VDC Battery System
45VDC For 36VDC Battery System
60VDC For 48VDC Battery System
Max Solar Voltage : 100VDC For 12VDC Battery System
245VDC For 24/36/48VDC Battery System
LCD display , easy to operate on LCD screen
Multi stage charging (3-stage charging , parallel charging and equalized charging function)
BTS – Battery remote temperature sensor terminal
Enable to charge Lithium, Gel , lead-acid battery
With RS485 & USB communication port
Protection: PV array short circuit, PV reverse polarity, Battery reverse polarity, Over charging, Output short circuit
