SPECIFICATION

 System General

• Operating Frequency Range : 2400 MHz-2483.5 MHZ
• Transmitting Power : 17dBm Max
• Monitor Sensitivity : -88dBm
• Type of Spread Spectrum TX : FHSS
• Type of Modulation : GFSK
• Data Rate : 3Mbps
• Transmission range : Outdoor 100 m (Eye of Sight)
• Operating Temperature Range : 0°C-+40°C
• Operating Humidity Range : 85% RH
• Environment Rating : Indoor use only

                                      Wireless Camera

• Image Sensor Type : 1 /3″ Color CMOS Image Sensor
• Effective Pixel : H: 640, V: 480
• Lens : EFL=3.6mm. F=2.8
• Viewing Angle (Diagonal) : 70 degree
• IR LED Type/ Night Vision : 7pCS IR LED  5m
• Power Requirement : DC 5V
• Other Special Feature : Built in Microphone/ Speaker

                                    Wireless Monitor

• Display Type/Size  : Color TFT 2.4″
• Resolution (Pixel)  : 960X240(RGB)
• Viewing Angle  : H:80 degree, V:100 degree
• Power Requirement : Adapter DC 5V
• Battery : 3.7V Li-polymer
